Item specifics
  • Brand Name: SEAFLO
  • Voltage: 12V
  • Rated Current: 16 - 21A
  • Certification: CE,ISO9001:2000,RoHS
  • Flow Rate: < 500GPH
  • Model Number: SFDP1-050-070-52
  • Structure: Diaphragm Pump
  • Power: Electric
  • Certification: CE, ISO9001:2008, RoHS
  • Pressure: 70PSI/4.8bar
  • Application: Marine/RV,Recreation,Agriculture,Industry
  • Amps: 18.0A Max
  • Flow Rate: 5.0 GPM (18.9 LPM)
  • Duty Cycle: Continuous
  • Motor Type: 12V DC permanent magnet, totally enclosed, non-ventilated
Product Description



SEAFLO 12V 5GPM 70PSI Electric Water Diaphragm Pumps Self priming RV Boat Marine Agriculture



Features

  • Positive displacement pump
  • Can run dry
  • Quiet operation
  • Demand Pump
  • Easy connect fittings
  • Industry standard mount pattern

Applications

  • Water Treatment/RO
  • Agricultural Spraying
  • General Industrial
  • Automotive
  • Alternative Energy/Solar
  • Agriculture and RV

22





Pump

Type

5 Chamber positive displacement diaphragm
pump, self priming, capable of being run dry

Max Recommended Temperature

140°F (60°C) Max.

Priming Capabilities

6 feet (1.8 m) suction lift

Max Pressure

70PSI (4.8bar)

Inlet/Outlet Ports

Quick Attach

Weight

6.0 lbs (2.7 kg)

Motor

Duty Cycle

Continuous

Leads

16 AWG, 4.5" long with 2-Pin connector/Leads

Voltage

12v



Technical Parameters

52





STANDARD PUMP CONFIGURATIONS

Model

Voltage

GPM/LPM

Switch

Amps

PSI/BAR

Valves

Diaphragm

Ports

Wire

Connections

SFDP1-050-070-52

12V

5.0/18.9

Demand

18.0 MAX

70/4.8

EPDM

Santoprene

Quick Attach

2-Pin/Leads






















Certification



Packaging Details
  • Unit Type: piece
  • Package Weight: 3.5kg (7.72lb.)
  • Package Size: 29cm x 16cm x 14cm (11.42in x 6.30in x 5.51in)
